Specifications
XAG R200
Net Weight
130 kg (with Onboard RevoSpray)
Max. Payload
240 kg (with Onboard RevoSpray and battery)
Wheel Track
705 mm
Wheelbase
950 mm
Min. Ground Clearance
270 mm
Min. Turning Radius
0 m; supports on-the-spot turning
Max. Speed
1.5 m/s
Max. Gradeability
20%
Operating Ambient Temperature
0–40 °C
Powertrain
Drivetrain
Independent 6WD; differential steering
Number of Motors
6
Protection Rating
IPX6
Rated Motor Power (Single Motor)
100 W
Tyre Size
16-inch pneumatic tyre
Tyre Inflation Pressure
30 psi
RevoSpray System
Smart Liquid Tank
Liquid Tank Rated Capacity
240 L
Flexible Impeller Pumps
Quantity
4
Single Pump Flow Rate
2–4 L/min
Max. Flow Rate
16 L/min
JetSprayer
Quantity
4
High-Speed Centrifugal Nozzle Quantity
4
Droplet Size
60–200 μm
Spray Width
Max. horizontal range per side: 7 m
Max. spray height: 1.5 m (depending on operating speed, wind speed, environment, etc.)
Gimbal Adjustment Angle
Horizontal rotation: 180°
Vertical tilt: −10°–90°
Control & Perception System
Vehicle Control
Vehicle Control System
SuperX 5 Ultra Intelligent Control System
Wide-Angle FPV View
Video Resolution
1920×1080
Power Supply Voltage
24 V
Frame Rate
30 FPS
Video Encoding Format
H.265
Image Sensor
1/2.7-inch CMOS-RGB image sensor; 5 effective megapixels
Focal Length
1.83 mm
Field of View (FOV)
Horizontal: 150°
Vertical: 105°
SRC5 Remote Controller
Model
M3SRC5AH
Dimensions
260mm x 140mm x 89mm
Weight
1.2 Kg
Operating System
Android
Battery Capacity
20000mAh (3.65V)
Charging Protocol
Supports QC Charging protocol
Charging Ambient Temperature
5°C to 40°C
Operating Ambient Temperature [8]
-10°C to 40°C
Storage Ambient Temperature
-20°C to 55oC Less than a Month
-20°C to 45°C One to three months
-20°C to 25°C Three months to one year
Charging Voltage / Current
5V⎓3A, 12V⎓2.5A, 15V⎓3.0A
Max Transmission Distance [9]
(Unobstructed, free of interference)
SRRC: 2000 Meters
FCC: 2000 Meters
CE/MIC: 1000 Meters
Voice Prompt
Yes
Screen Brightness
1200 cd/m2
Screen Resolution
1920 x 1200
Screen Size
7.02 inches
Screen Frame Rate
60 fps
Compatible Aircraft
XAG® P150 Max Agricultural Drone
Operating Frequency (Wi-Fi)
2.400 - 2.4835 GHz; 5.725 - 5.850GHz
Effective Isotropic Radiated Power
(Wi-Fi)
2.400 GHz ~ 2.4835 GHz
≤33 dBm (FCC)
≤20 dBm (CE/SRRC/MIC)
5.725 GHz ~ 5.850 GHz
≤33 dBm (FCC)
≤30 dBm (SRRC)
≤13.98 dBm (CE)
Operating Frequency (Bluetooth)
2402 MHz ~ 2480 MHz
Effective Isotropic Radiated Power (Bluetooth)
≤10 dBm
2G Operating Frequency
CE: GSM900: 800 – 915 MHz
925 – 960 MHz
DCS1800: 1710 – 1785 MHz
1805 – 1880 MHz
FCC: GSM850; PCS1900
ANATEL: GSM850, GSM900, GSM1800, GSM1900
2G Max. Transmit Power
Class 1 (30 dBm ±2 dB) for DCS1800
Class 4 (33 dBm ±2 dB) for GSM900
3G Operating Frequency
CE: WCDMA Band 1 1920 – 1980 MHz
2210 – 2170 MHz
WCDMA Band 8 880 – 915 MHz
925 – 960 MHz
FCC: WCDMA B2, WCDMA B4
KCC: WCDMA B1
ANATEL: WCDMA B1, WCDMA B2,
WCDMA B5, WCDMA B8
MIC: WCDMA B1, WCDMA B5,
WCDMA B6, WCDMA B8,
WCDMA B19
3G Max. Transmit Power
Class 3 (24dBm + 1/-3 dB) for WCDMA bands
4G Operating Frequency (LTE)
CE: LTE B1, LTE B3, LTE B7, LTE B8,
LTE B20, LTE B28, LTE B38, LTE B40
FCC: LTE B2, LTE B4, LTE B5, LTE B7,
LTE B25, LTE B26, LTE B38, LTE B41
KCC: LTE B1, LTE B3, LTE B5, LTE B7, LTE B8
ANATEL: LTE B1, LTE B3, LTE B5, LTE B8, LTE B25
LTE B26, LTE B28, LTE B39, LTE B40, LTE B41
MIC: LTE B1, LTE B3, LTE B5, LTE B8, LTE B18
LTE B19, LTE B26, LTE B41
4G Max. Transmit Power
Class 3 (23 dBm ±2 dB) for LTE bands
GNSS Frequency Band
BDS: B1
GPS: L1C
GLONASS: L1
Galileo: E1
Smart Battery
General Information
Model
M1PPA141050AH
Dimensions
192mm x 139mm x 315mm
Weight [10]
Approx. 7.1 kg
Battery Type
Lithium Polymer (LiPo) Battery
Performance Specifications
Rated Capacity
20,000 mAh
Energy
1050 Wh
Rated Output
52.50V / 140A
Max Charging Current
120A
Environmental Specifications
Operating Temperature
10°C to 45°C
Charging Temperature
10°C to 40°C
Storage Temperature
10°C to 30°C
IP Rating [11]
IP65
Compatibility
Compatible Aircraft
XAG® P150 Max Agricultural Drone
Compatible Chargers
XAG® CM13600S Battery Charger
XAG® CM15300D Battery Charger
XAG® CM210600 Battery Charger
Battery Charger
Model
M2CM13600CH
Compatible Battery
XAG B141050 Supercharge Battery
XAG B13970S Supercharge Battery
Dimensions
346.00mm x 109.00mm x 73.00mm
Weight
Approx 3.9 Kg
Operating Temperature
-20°C to 40°C
Cooling Mode
Forced Air cooling
Input Voltage
AC 100-120 Vac 50/60 Hz 15.0A
AC 220-240 Vac 50/60 Hz 16.0A
Output Voltage
59.92 Vdc⎓21A
59.92 Vdc⎓55A
Output Power
35A (Max)/1300 W (100-120 Vac 50/60 Hz)
80A (Max)/3400 W (220-240 Vac 50/60 Hz)
Compatible Batteries
XAG® B141050 Supercharge Battery
XAG® B13970S Supercharge Battery
XAG® B13960S Supercharge Battery
