Specifications
XAG APC2
Model
XAPC2AHBD-2.5RD
Steering Control
Electric steering wheel
Operating Accuracy
Line accuracy ≤ 2.5 cm, spacing accuracy ≤ 2.5 cm
IP Rating
IP67
Overall Dimensions
452*452*230mm
Overall Weight
7.45 kg
Mainframe
Dimensions
115×202×150 mm
RTK Positioning Accuracy (RTK FIX)
Horizontal: 1 cm+1 ppm
Vertical: 1.5 cm+1 ppm
Wireless Frequency Band & EIRP (CE)
LTE-FDD (with receive diversity): B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28
LTE-TDD (with receive diversity): B38/B39/B40/B41
WCDMA (with receive diversity): B1/B2/B4/B5/B6/B8/B19
GSM: 850/900/1800/1900 MHz
PPP Positioning Accuracy
< 20 cm
GNSS Receiver Antenna
Single antenna
Radio Tranmitter Power
≤ 20 dBm (EIRP)
Integration Components
Satellite antenna, controller, satellite receiver PCB module, and INS
Power Input
DC 24 V
GNSS
BeiDou/GPS/GLONASS
RTK Signal Loss Tolerance
10 min
Operating Temperature
-20 ℃ ~ 70 ℃
Storage Temperature
-40 ℃ ~ 85 ℃
Motor
Dimensions
88×269×170 mm
Steering Wheel Diameter
400 mm
Rated Voltage
DC 12V~24V
Max. Voltage
28 V
Insulation Voltage
500 VDC
Torque
Rated: 10 N·m, Max.: 20 N·m
Enhanced Auto Steering Wheel
Dimensions
236×178.8×68.5mm
Rated Voltage
12V~24V
Max. Voltage
32V
Min. Voltage
9V
Insulation Voltage
500 VDC
Torque
Rated: 10 N·m, Max.: 20 N·m (Test Voltage 12V)
Operating Temperature
-20 ℃ ~ 70 ℃
Storage Temperature
-40 ℃ ~ 85 ℃
Protection Rating
IP67
Steering Wheel Diameter
400 mm
Steering Motor Drive
Dimensions
298×243×79 mm
Rated Voltage
12 V ~ 24 V
Max. Voltage
32 V
Min. Voltage
9 V
Insulation Voltage
500 VDC
Torque
Rated: 8 N·m, Max.: 16 N·m (Test Voltage 12 V)
Operating Temperature
-20 ℃ ~ 70 ℃
Storage Temperature
-40 ℃ ~ 85 ℃
Protection Rating
IP54, Core Parts IP67
XAG XRE1 Range Extender User Manual
Dimensions
73× 73× 161 mm
Rated Voltage
12 V ~ 24 V
Max. Voltage
32 V
Min. Voltage
9 V
Power Consumption
2.5 W
Operating Frequency
2.400~2.467GHz
5.725~5.850GHz
Effective Isotropic Radiated Power (EIRP)
2.400 5.725 ~ ~ 2.467 5.850 GHz: ≤ 20 GHz: ≤ 33 dBm
Operating Temperature
-20 ℃~70 ℃
Storage Temperature
-40 ℃ ~ 85 ℃
Protection Rating
IP67
XAG XRE1 Range Extender User Manual
Dimensions
73× 73× 161 mm
Rated Voltage
12 V ~ 24 V
Max. Voltage
32 V
Min. Voltage
9 V
Power Consumption
2.5 W
Operating Frequency
2.400~2.467GHz
5.725~5.850GHz
Effective Isotropic Radiated Power (EIRP)
2.400 5.725 ~ ~ 2.467 5.850 GHz: ≤ 20 GHz: ≤ 33 dBm
Operating Temperature
-20 ℃~70 ℃
Storage Temperature
-40 ℃ ~ 85 ℃
Protection Rating
IP67
WCP1 Wireless Control Panel
Dimensions
156×103×33 mm
Resolution
320×480
Screen Size
4 inches
Screen Brightness
≥ 700 nit
Battery Capacity
5000 mAh
Charger Port
TypeC
IP Rating
IP67
Input Voltage
5 VDC (Max)
Standby time
11.5 hours
Working time
4-8 hours
